Product Overview.
Aaztec AX-S04 3-in-1 controller is designed for LED display solutions, integrating a professional video processor, LED sending card, and offline media player into a single device with four network ports. It simplifies LED system configuration and on-site debugging, making large-screen setup easy with just one device.
Key Features:
- 4 network ports, max load of 2.6 million pixels, up to 4096 (W) x 2048 (H).
- Arbitrary wiring: port load is unrestricted by rectangular layout.
- USB playback supports multiple video and image formats.
- Supports multiple digital inputs: 2x HDMI 1.3, 1x DVI-D, 1x USB.
- 3.5mm audio output with synchronized audio and video output
- EDID Management: read/- modify/customize EDID.
- Built-in test patterns : solid color, gradient, scan line, etc.
- Freeze-frame with one key.
- Black border removal/cropping: crop any signal to fill screen.
- Real-time adjustment of brightness and contrast.
Technical Specifications
| Interface | Qty | Description |
|---|---|---|
| HDMI | 1 |
Supports maximum input resolution: 2048x1l52@60Hz Supports Custom max: 2048×1200 8-bit video input, HDCP 1.4 Supported color spaces/sampling rates: RGB 4:4:4 / YCbCr 4:4:4 / YCbCr 4:2:2 Supports embedded audio input Does not support interlaced signal input |
| HDMI/VGA | 1 |
Supports maximum input resolution: 2048×1l52@60HZ Supports custom resolutions: width: 2048 & Height: 1200 8-bit video input, HDCP 1.4 Supported color spaces/sampling rates: RGB 4:4:4 / YCbCr 4:4:4 / YCbCr 4:2:2 Supports embedded audio input Does not support interlaced signal input |
| DVI | 1 |
Supports maximum input resolution: 2048×1l52@60HZ Supports custom resolutions: width: 2048 & Height: 1200 8-bit video input, HDCP 1.4 Supported color spaces/sampling rates: RGB 4:4:4 / YCbCr 4:4:4 / YCbCr 4:2:2 Supports embedded audio input Does not support interlaced signal input |
| USB | 1 |
Supports playback of videos or images stored on the USB drive USB drive input for media playback Max resolution: 1920×1080@60Hz NTFS format, up to 2TB FAT32 format, up to 192GB Supports embedded audio input with video playback. |
